NB ACC DOCKING STATION/USB-C 100W CSV-1564W100 CLUB3D
216,43 €
5 laos
Tellitud: 0
Saadaval olevad esemed: 5
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Interpretation and Definitions
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
XS
0 ( 000 )
23
32
44
55
S
24
23
32
44
55
M
25
23
32
44
55
L
26
23
32
44
55
M
29
23
32
44
55
L
32
23
32
44
55
M
34
23
32
44
55
4 - Päeva Transport
mai 01 mai 05
Kirjeldus
Tootja kood (MPN): CSV-1564W100
ELKO kood: 1427790
Description: USB Type C 3.2 Gen1 Triple Display Dynamic PD Charging Dock 100W PD Power charger
CSV-1564W100 – The Club-3D USB 3.2 Gen1 C Triple Display Dynamic PD Charging Dock is an integrated solution combining Video, Data, Power, Ethernet and Audio especially for frequent travelers. The Three different Video ports(HDMI™, DisplayPort™, VGA) allow you to enjoy 3 different images or videos on 3 different displays simultaneously under MST mode. The USB Type A ports and USB Type C data port allow you to connect multiple USB devices to the host. The USB Type C charging port allows you to provide power for this Dock and can charge the host PC at the same time by connecting a PD power Adapter, no need to carry your Notebooks Power Supply.
So in general the user is travelling lighter. The Micro SD and SD/MMC ports allow you to read information in the memory card onto the host. The 3.5mm audio port allows enjoying music of the host via a headset. Besides, with the Gigabit Ethernet port, you can enjoy high speed Ethernet on the host. It supports all DP Alt mode supported hosts. (PC, laptop, mobile phone, etc.) Dynamic Current Detection and Power Distribution, the product no longer intercepts the fixed power from the external PD Power Supply, but intercepts it according to the actual power consumed by itself, so that the PC can be dynamically charged more power.
For Video Signal the source device needs to support DisplayPort™ Alt Mode.
Features:
• Supports DP Alt Mode and PD 3.0
• Supports max. 5Gbps data transmission on the USB 3.2 Gen1 Type C ports
• One USB 3.2 Gen1 Type C Data port
• One USB 3.2 Gen1 Type C port supports PD charging with max 100W (20V/5A) Bundled with 100W Power Supply (for Notebooks with current consumption up to 100W)
• HDMI™ max. 4K30 Hz
• DP™ max. 4K30 Hz
• VGA max. 1920×1200 60Hz
Vendor Homepage: www.club-3d.com/en/detail/2608/usb_type_c_3.2_gen1_triple_display_dynamic_pd_charging_dock_100w_pd_power_charger/
Model: CSV-1564W100
Model name: USB Type C 3.2 Gen1 Triple Display Dynamic PD Charging Dock 100W PD Power charger
15pin D-sub: 1
DisplayPort: 1
HDMI: 1
Headphones jack: 1
MicroSD Card Slot: 1
RJ45: 1
SD Card Slot: 1
USB 2.0: 2
USB 3.0: 3
USB-C: 3
Included Accessories: • PowerSupply 100 Watt
• 2x USB Type C cable: 1x connection to Host 27cm / 0.886ft, 1x RED cable USB type C for charging to PowerSupply 1 m / 3.28 ft
• Quick Install Guide
Dimensions: 35 x 7.5 x 2 cm
Units per Shipping Box: 1
Shipping Box Depth: 37
Shipping Box Height: 7.5
Shipping Box Weight: 0.72
Shipping Box Width: 11
Unit Calculated Volume: 0.003053
Product Net Weight: 0.71
Unit Calculated Weight: 0.72
Unit Box Width: 0.11
Unit Box Length: 0.37
Unit Box Height: 0.075
Full Description Line: Model name USB Type C 3.2 Gen1 Triple Display Dynamic PD Charging Dock 100W PD Power charger|1x15pin D-sub|1xHDMI|1xDisplayPort|2xUSB 2.0|3xUSB 3.0|3xUSB-C|1xHeadphones jack|1xSD Card Slot|1xMicroSD Card Slot|1xRJ45
Category Code: NBK
